Function characteristics:

↘ analog mixer, high-quality low noise circuit design, dynamic allowance

↘ 8 channel mic/line input

↘ channel equalizer, two wave sound warm, strong musicality

↘ per channel 1 putter rear effect delivery, used for external effect, equipment

↘ 16 built-in DSP digital reverb

↘ USB access design, with LCD display, can be directly inserted into the U disk MP3 music

↘ 48 v phantom power supply, support capacitor microphone to use directly

↘ 5 stereo equalizer output design master

↘ stereo headphones listening/audio output

↘ 2 road with high level display

↘ 60 mm high degree of analysis and durable pusher

↘ high quality components and extremely strong structure, product durability

Technical parameters:

↘ maximum output level: 19 DBM (1 KHZ, THD = 0.5%)

↘ signal-to-noise ratio: 80 db or less

↘ equivalent noise input electromotive force: - 115 DBM

↘ headphone output power: 100 mw (1 KHZ, THD = 0.5%, 200 Ω)

↘ gain control: mono - 60 db to - 40 db

↘ frequency response: 20 hz - 20 KHZ - (plus or minus 3 db)

↘ total harmonic distortion plus noise: 0.003% or less (1 KHZ, 0.775 V)
