LCC - 5536 - m central control console using TCP/IP network communication, support through local area network or the Internet control, support the/Iphone or computer as a terminal operation. Provide the APPLE official certification of control system, to ensure the system stable and compatible, more do not need to escape, without crack, allowing you to use more convenient, more at ease. Can operate splicing wall, projection, video camera, lighting, curtain, curtain, television, set-top boxes, air conditioning, conference system, AV \ VGA \ RGB audio and video matrix switchers and so on.

↘ control communications: Ethernet (TCP/IP), 10/100 m adaptive, TCP SERVER mode, also to customize for UDP.

↘ processor: embedded processor. Using 2 embedded high-speed central processing unit (CPU) parallel computing, is different from the traditional control system, can quickly handle all kinds of complex control instruction, improve the speed of response to a user

↘ ir port: 8 road independent programmable infrared interface, support to control many sets of the same or different infrared devices, support to control the DVD, TV, air conditioning, projectors and other all infrared remote control device;

↘ infrared learning: built-in, support long code identification.

↘ instruction memory: FLASH, large capacity FLASH memory, it can store up to 2048 control instruction, can satisfy the demands of any occasion control storage, support extension;

↘ relay: 8 road weak current relay interface, used for curtain, electric curtain control;

↘ Rs232 serial port: 16 road, programmable, RS - 232 serial port, and the RS - 485 unrelated, can be used at the same time;

↘ / RS485 serial port 422:8 road, programmable, RS - 485 serial port, and the RS - 232 unrelated, can be used at the same time;

↘ Io mouth: 2 road, supports external high level trigger actions or output high level;

↘ camera tracking: support;

↘ support computer control, touch screen control;

↘ support Internet remote programming, remote maintenance, remote upgrade, saves the cost of after-sales;

↘ power output: 5 v power supply output;

The overall parameters:

↘ power: 100 vac ~ 240 vac, 50/60 hz, the maximum power: 15 w;

↘ size: 480 mm (length) x 250 mm x 85 mm (deep) (high)

↘ installation: standard 19 inch rack, 2 u
