LS1400

Product features:

Line array loudspeaker using the latest source of design concept, with perfect pointing to the characteristic and frequency response consistency. Clearance between LS1400 box body and box body have shrink to a minimum, thus reducing the noise of the whole array is invalid area, minimize the vertical sidelobe array.

Can be simple, quick and reliable hoisting structure hanging into vertical line array; Ultra-low frequency speakers will also be on the ground, and special brace linear array loudspeaker; Also lifting framework, through professional hanging rack directly installed on the wall to use, USES can get further development.

Applicable fields:

Designed for all kinds of large-scale conference, auditorium, banquets and other places design, system operator's consistent high praise with good quality and advanced amplification technology and support services.

Technical parameters:

System: H3 "x12 & F2.5 x36"

The highest sound pressure level: 118 db

Frequency response: 200 hz - 20 KHZ (plus or minus 3 db)

Color: black

Nominal resistance: 8 Ω

The hanging system

Butterfly to hang: soft rope hanging state

Power: 240 w / 4 Pcs x3 (RMS)

Size: 400 x76x1260mm

The sensitivity level: 105 db

Weight: 30 kg

Set the standard:

LS1400-12 x: 2 string

DF400 subwoofer: 2 only

GF400 amplifiers channels (4) : 2 sets

DS60 processor: 1
