LP - 7900 - m central processing unit
Vote/vote/check-in/video tracking discussion system consists of hardware and software, adopt intelligent digital control technology, to connect the computer with USB interface, the TCP/IP network interfaces, WiFi LAN and RS232 serial port control and so on a variety of choices, support the venue layout, online testing, the meeting microphone on/off control. Realize multi-function, can be separated from computer and simple operation of a new generation of fully functional digital video tracking meeting system, widely used in the hall, hotels, Banks, companies of any size conference room and big international languages conference center.
↘ support WiFi network data exchange, wireless control CPU all control functions, brings great convenience to use and engineering installation of equipment maintenance.
↘ with TCP/IP network interface for remote control and remote assistance
Hot swap ↘ support system, the host screen support Chinese/English menu operation and calendar display
↘ support RS232 central control, and has the function of two-way sending, and control to achieve perfect coordination
↘ receiver unit has four road input channel receiver unit can pick up 100
↘ has two cascade port, and support multiple hosts cascade can pick up 2500 units, at the same time for the meeting
↘ supports external audio recording input and output
↘ support telephone conference access port
↘ system can be set up locking or remove the function of the microphone is operating, including the language selection
↘ system input and output with electronic volume control function, effective to eliminate noise
↘ speech model has: fifo, lifo, automatic mode, discussion, chairman
↘ have acoustic open microphone and speak limited-time functions 1-999 seconds (optional)
↘ connect computer with USB interface, the TCP/IP network interfaces, WiFi network and RS232 serial port control options
↘ connect computers can simulate the site meeting scene layout, may at any time click open or shut down all of the cell phone
↘ support PELCO P/D, SONY EVID70 RS422 camera deal
↘ support 4 sign video switching, and with an external RS232 video switching protocol port support hd video matrix switch connection.
